Photography

The Photographs on the left shows my basic setup for “still life” shots but is largely applicable to my workshop shots also. The main flash points into the metal dome reflector seen on the right of the camera but this can be on the left and occasionally above the camera depending the requirements of the item being photographed.



I almost always use a tripod for the camera, the only exception being when there is insufficient space for the tripod to stand. Whilst the flash gun points into the reflector it is of the type that allows the head to pivot through 180 degrees, the auto sensor that determines the duration of the flash can therefor still point directly at the item being photographed. I have included three photographs below to illustrate the difference between direct flash, reflected flash and with added fill in flash.



In the left hand picture the head of the flash gun was pivoted so that it pointed directly at the item being photographed. It can be seen that the result is a very pronounced shadow, even to the point that the holes in the dividing plate clearly show up.



In the middle picture the head was turned to face into the reflector as is always my method and it can be seen that the shadow is much less clearly defined, it is though still quite dark. Even so, it is still a much better picture than the first.



In the right hand picture the small flash gun (see the picture on the previous page) with the slave unit fitted was held to the left of the camera which then fired in synchronization with the main flash. The flash is held with a loop of paper around the front of it  to prevent its beam being too direct else its result would be similar to that in the left hand picture. In this the shadow is now much more subdued but there is just evidence of the added flash by the fact there is now a very light shadow on the right of the dividing head. The picture is a major improvement, even over the one in the centre.



In the absence of a second flash gun a sheet of white faced hardboard, or some other comparable item, would reflect light from the main flash and give a similar, if less pronounced, result.

Reflected flash
Direct flash
Fill in flash

Construction of the Dividing Head featured was published in MEW issues 53 and 54, also WPS book no.37 Dividing


Workshop Photography

Click on the pictures for larger views
